CGR CGRA engine code 3.6 FSI VR6 used connecting rod

VR6 3.6 FSI Connecting Rod (03H 198 401 A)

3.6L VR6 EA390 CGR / CGRA — Forged Steel, Fracture-Split, I-Beam Profile

OEM forged steel connecting rod from the Volkswagen Group EA390 VR6 3.6 FSI naturally aspirated engine (engine code CGR / CGRA, block casting 03H 021 AJ). This precision-engineered I-beam connecting rod features fracture-split (cracked cap) big end technology — the jagged mating surface visible on the cap joint ensures perfect realignment during assembly, superior to conventional machined surfaces. The rod is milled from forged steel (not cast), with a trapezoidal small end eye design unique to the VR6 platform. Center-to-center length is 164 mm (6.457"), with a 20 mm wrist pin bore at the small end and approximately 56.7 mm journal diameter at the big end. The connecting rod bearings are molybdenum-coated for reduced friction and extended service life. Visible forging identification marks are stamped into the big end area. Rod bolt torque specification is 30 Nm + 90° (angle-torque method). Six of these connecting rods operate in the narrow-angle (10.6°) VR6 configuration, translating the linear force of the 89.0 mm bore pistons through a 96.4 mm stroke to produce 3,598 cc of displacement. The VR6 3.6 FSI engine delivers between 206 kW (280 PS) and 221 kW (300 PS) depending on variant, and is renowned for exceptional durability, routinely exceeding 400,000 km.
