21136-03920 G4LC HYUNDAI KIA UPPER OIL SUMP

Hyundai/Kia G4LC Upper Oil Sump 21135-03920

Kappa II 1.4L MPI — Aluminium Upper Oil Pan, Two-Piece Design

Aluminium upper oil sump (upper oil pan) for the Hyundai/Kia G4LC Kappa II 1.4-litre MPI inline-4 engine, casting number 21135-03920. Manufactured by Hyundai Motor Group with both Kia and Hyundai logos cast into the housing. This two-piece oil pan design features the structural upper section that bolts directly to the engine block, incorporating the main bearing ladder frame, oil drain plug boss, oil filter housing mount, and multiple bolt holes for the lower sump attachment. Engine code: G4LC. Displacement: 1,368 cc. Bore: 72 mm, Stroke: 84 mm. DOHC 16V with D-CVVT (dual continuously variable valve timing). Multi-point fuel injection (MPI). Compression ratio: 10.5:1. Power: 73–74 kW (99–100 HP) at 6,000 rpm. Torque: 132 Nm at 4,000 rpm. Production: 2015–present. A high-volume Hyundai Motor Group platform powering compact cars across both Hyundai and Kia brands worldwide.
